Kit Leviathan Blackbird "The 1350"-325-75 - Modular Backtail

Full kit “The 1350” Leviathan Blackbird: The Ecosystem of Perpetual Flight

Domina l’arte del pumping infinito. Il glider 1350 Blackbird unisce la leggendaria ala "THE 1350" a un sistema modulare in carbonio per un'esperienza di volo precisa e "salva-sessione".


Complete your set – Get more value


Kit Leviathan Blackbird "The 1350"-325-75 - Modular Backtail specs
TOP SPEED
LIFT
GLIDE
MANEUVERABILITY
PUMPING

Product Line Blackbird
Range Leviathan
Recommended for Freeride - Dock-Start - Downwind - SUP - Pumping
Take Off Speed 7 - 9 kn
Top End Speed (average 80kg user) 13 - 15 kn

Beyond the Margin of Error

High-aspect efficiency usually comes with a price: punishing stall speeds and a razor-thin margin for error. Whether you are navigating a technical rock start or hunting for glides on a glassy lake, most foils demand perfection. A single mistimed pump often ends the session. The KIT 1350 Blackbird is the solution for riders who value flight time over swimming, balancing elite performance with the forgiveness needed to "save" every ride.

THE 1350 & Active-Lift Synergy

The centerpiece of this kit is “THE 1350”, a wing that has been redesigned to work in perfect harmony with our Active-Lift technology. By engineering the system to generate its own hydrodynamic lift, we’ve effectively "unlocked" the wing’s potential. This allowed us to refine the profile of THE 1350, making it thinner and faster while retaining the massive lift and legendary accessibility the Leviathan is known for.

Supporting this powerhouse is the FC/M Modular back-fuselage. This full carbon backbone provides the ultimate platform for customization: its modular nature allows you to swap to your preferred stabilizer and use shims for precise tuning. This means you can micro-adjust the angle of attack to match your pumping cadence and weight, ensuring the system feels like a natural extension of your body. Paired with the SF/325 flat stabilizer, the setup minimizes drag and maximizes agility, turning a high-surface wing into a responsive carving machine. Finally, the M75/BB ultra-high modulus mast with W-Core technology ensures a direct connection between board and hydrofoil for the best performance.

Tech & Feel

  • THE 1350” Front Wing: The heart of the system. Experience a perpetual glide sensation with a wingspan that provides rock-solid stability and effortless low-speed take-offs.

  • Active-Lift Integration: The system creates a "weightless" feel underfoot, significantly lowering the stall speed and allowing you to recover from missed pumps that would ground other foils.

  • FC/M Modular Fuselage: A rigid, full carbon connection that offers total tuning freedom. Use shims to dial in your ride or swap stabilizers to adapt to different conditions.

  • Flat 325 Stabilizer: Engineered for pure hydrodynamics. Its flat profile reduces drag to the absolute minimum, facilitating higher top-end speeds and agile rail-to-rail transitions.

  • Full Carbon Responsiveness: Every ounce of energy from your legs is translated into forward drive. The structural stiffness of the kit ensures zero power loss during high-intensity pumping.



Dimensions & Advanced specs
Front Wing - Span 1350 mm
Front Wing - Surface 1864 cm2
Front Wing - Aspect Ratio 9,8
Front Wing - Root Chord 170 mm
Front Wing - Maximum Thickness 21 mm
Stabilizer - Span 325 mm
Stabilizer - Surface 155 cm2
Stabilizer - Aspect Ratio 7,1
Stabilizer - Root Chord 58,9 mm
Stabilizer - Maximum Thickness 6,4 mm
Fuselage - Total Length 690 mm
Mast - Height 750 mm
Mast - Board Connection Carbon Plate
Foil Set - Weight (ca.) 4,5 kg

Content

Download manuals and documents
Blackbird - User Manual
