K91633
Kit M91 - W633 - S483 - FS710



The funniest foil on the market, capable of transforming any body of water into a real playground for foils.

K91633... Thousands of riders have bought this combination, the reason is simple: it the funniest foil on the market, capable of transforming any body of water into a real playground for foils.
Low aspect ratio (3.3 AR), moderate inverted gull wing, concave bottom design. This full carbon wing will take your foiling experience to the next level.
The W633 combined with the S483 stabilizer allows you to foil from walk speed up to 25 knots. The W633/S483 combo is the choice for all those riders aiming to learn new manoeuvres, surf small waves and progress their abilities.








DIMENSIONS & ADVANCED SPECS

Base Plate Joint | 90x165mm |
---|---|
Mast Height | 910mm |
Front Wing Span | 633mm |
Front Wing Root Chord | 256mm |
Front Wing Aspect Ratio | 3,3 |
Front Wing Surface | 1239cm2 |
Stabilizer Span | 483mm |
Stabilizer Root Chord | 85mm |
Stabilizer Aspect Ratio | 7,6 |
Stabilizer Surface | 316cm2 |
Kit Weight | 3468 gr +/- 5% |
content
M91 - Carbon Plate mast 91 | 1 |
---|---|
FS710 - Fuselage 710 | 1 |
W633 - Carbon Front Wing 633 | 1 |
S483 - Carbon Stabilizer 483 | 1 |
Socket head cap Screw M6x25mm and washers | 2 |
Flat Head Screw torx M6x30mm | 3 |
---|---|
Flat Head Screw M6x16mm | 1 |
Flat Head Screw M6x20mm | 1 |
Grease, torx, hex tip | |
Instructions |
M91 - Carbon Plate mast 91 | 1 |
---|---|
FS710 - Fuselage 710 | 1 |
W633 - Carbon Front Wing 633 | 1 |
S483 - Carbon Stabilizer 483 | 1 |
Socket head cap Screw M6x25mm and washers | 2 |
Flat Head Screw torx M6x30mm | 3 |
Flat Head Screw M6x16mm | 1 |
Flat Head Screw M6x20mm | 1 |
Grease, torx, hex tip | |
Instructions |
