FULL-CARBON PLATE

C83799K - M83K - W799 - S430 - F703K - CP02K

SKU: C83799K
Availability: In stock
Purchase and earn 1880 points
€1,880.00

WING FOIL
M83K - W799 - S430 - F703K - CP02K

Hydrofoil Set C83799K- Full Carbon Plate | KMS

Recommended for Freestyle and Freeride


M83K - W799 - S430 - F703K - CP02K specs
LIFT
MANEUVERABILITY
TOP SPEED
EASE OF PUMPING
EASE OF USE

Disciplines Wing
Recommended for Freeride - Freestyle
Mast Connection System Kraken Modular System

This kit, developed in collaboration with pro-rider Balz Muller and enhanced with a full-carbon plate, is ideal for Wing-Foil, in particular for Freestyle and Freeride in moderate-strong winds.

Thanks to the Kraken Modular System connection system, maximum compatibility with all components of the same SABFOIL range is guaranteed, so that you can change your setup at any time, without any problems.

The kit C83799K consists of:

  • Mast: M83K - 830 mm

  • Front Wing: W799 - 1100 cm2

  • Stabilizer: S430 - 240 cm2

  • Fuselage: F703K - 703mm

  • Mast Plate: CP02K

It is possible to upgrade your kit thanks to the Quick Release System (Q01K) patented by SABFOIL and sold separately. Thanks to it you can assemble and disassemble your hydrofoil in a few seconds, avoiding at the same time losing the configuration on the board.

Click here for more information about Kraken Modular System



Dimensions & Advanced specs
Mast - Height 830 mm
Front Wing - Span 799 mm
Front Wing - Surface 1100 cm2
Front Wing - Root Chord 170 mm
Front Wing - Aspect Ratio 5.8
Stabilizer - Span 430 mm
Stabilizer - Surface 240 cm2
Stabilizer - Root Chord 68 mm
Stabilizer - Aspect Ratio 7.7
Fuselage - Length 703 mm
Board Connection Type Carbon Plate
